FANUC 7.2 Inch Mono LCD Operator Panel P/N A02B-0200-C081

Technical Specifications

Model:A02B-0200-C081

Brand:FANUC

System compatibility:Separate type 7.2-inch monochrome LCD display unit for FANUC Series21-M CNC system. Installed on machine operation console,communicates with CNC main controller via dedicated cable. Widely used for old machining centers and CNC lathes equipped with 21-M CNC.

Function:Independent LCD display unit with 7 soft function keys. The monochrome LCD screen displays axis coordinates,NC part program,system parameters and alarm information. 7 soft keys for menu selection and function operation. Separate panel design,can be installed separately from MDI keypad unit. Connects to CNC mainboard through dedicated CNC signal cable.

Installation:Embedded panel cut-out mounting on machine operator console,dedicated signal connector for wiring.

Interface:

‑Dedicated CNC communication port for CNC main unit

‑7 soft keys on front panel

‑LCD driving signal terminals

‑Front LED status indicators

‑24VDC power connector

Circuit feature:LCD drive circuit,soft key scanning matrix,signal surge protection,panel configuration non-volatile memory.

Feature:Discontinued legacy FANUC Series21-M display unit. Separate design,MDI keyboard is sold separately. Confirm CNC system version before replacement. Common faults include backlight failure,display fading and soft key malfunction.

Diagnostic:Screen shows CNC boot information and alarm codes when powered;backlight damage will lead to dark screen,soft key failure causes menu selection abnormal.

Power supply:24VDC

Protection class:IP65 front panel;IP20 rear terminal area

Horizontal operating temperature:0℃ ~ +55℃

Storage temperature:-20℃ ~ +80℃

Relative humidity:5%‑90% non‑condensing

Vibration:Complies with machine tool industrial environmental requirement

Weight:1.8kg

Dimensions:240mm ×175mm ×55mm

Certification:CE

Built‑in function

A02B-0200-C081 7.2-inch monochrome LCD unit acts as HMI display for FANUC Series21-M CNC system. Operators monitor machine running data,check NC program and read system alarms. Widely used for CNC machine tool operator cabinet spare‑part replacement.

Product Brief

A02B-0200-C081 belongs to FANUC Series21-M spare parts family,separate monochrome LCD panel with 7 soft keys. This unit only contains display and soft keys,without MDI keypad. Verify CNC host model before ordering. Check signal cable and 24V power supply during commissioning. Widely applied for CNC equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
