Schneider 140CPS11100 Modicon Quantum AC Power Supply Module

Technical Specifications

Model：140CPS11100

Brand：Schneider

Product Type：Standalone AC power supply module,Modicon Quantum automation platform

Input Voltage：100‑276VAC,115/230V switchable,47‑63Hz

Rated Input Power：50 VA

Input Current：0.4A@115VAC,0.2A@230VAC

Backplane Output：5.1VDC,3A max

Operation Mode：Standalone only,non‑summable,non‑redundant parallel

Status Indicator：Green PWR‑OK LED

Protection：Overvoltage,overload,short‑circuit internal protection

Mounting：Quantum backplane rack slot installation

Weight：0.78kg

Protection Grade：IP20

Working Temperature：0℃ ~ +60℃,non‑condensing

Storage Temperature：‑40℃ ~ +85℃

Humidity：10%‑95% non‑condensing

Application：Water treatment,machinery,power auxiliary system,small‑size Quantum local rack maintenance and spare‑part replacement。

Product Details

140CPS11100 is standalone AC power supply for Schneider Modicon Quantum PLC racks,designed to supply 5.1VDC bus power for CPU,I/O and communication modules of local rack.

Input supports wide‑range 115/230VAC mains voltage,output maximum 3A for Quantum backplane. This unit works only in standalone mode,cannot be paralleled for current summing or N+1 redundancy. Green PWR‑OK LED gives visual power status feedback on front panel.

Built‑in overvoltage,overload and short‑circuit protection improves rack safety. Suited for small‑size local racks with limited module quantity. Widely used as replacement spare‑part for existing Quantum systems in water‑treatment,machinery and power auxiliary control field.
