Siemens 3VL8716-2AA30-0AA0 Moulded Case Circuit Breaker Unit

Module Feature

3VL8716-2AA30-0AA0 is a three-pole moulded case circuit breaker of Siemens 3VL series.

It adopts thermal-magnetic trip design. The thermal part provides inverse-time overload protection, and the magnetic coil offers instantaneous short-circuit protection. It supports optional auxiliary contact, alarm contact and shunt release accessories. It is widely used as spare part for industrial power distribution, pump and fan feeder protection cabinets.

Working principle

When overload occurs, the built-in bimetallic strip heats and deforms to trigger the trip mechanism.

When severe short-circuit fault appears, the magnetic component instantly generates electromagnetic force to pull the trip latch open, quickly separating the main contacts to cut off fault current and protect downstream cables and loads.

Onboard components

Bimetallic thermal trip element, magnetic trip coil, main contact assembly, arc extinguishing chamber, mechanical operating handle and flame retardant plastic housing.

LED indicators

No built-in LED indicator; circuit status is identified by the mechanical handle position.

Hardware self‑diagnosis

Manual inspection for contact wear, carbon accumulation inside arc chamber and mechanical latching condition. Trip setting is adjusted via front adjustment dial.

Programming software

Not applicable, locally adjustable circuit breaker.

Electrical & Process Parameters

Model: 3VL8716-2AA30-0AA0 Brand: Siemens Device type: Moulded case circuit breaker Function: Overload and short-circuit protection for low voltage distribution circuit

Mechanical & Structure

Mounting: Panel mounting inside distribution cabinet Protection class: IP40 (front panel) Housing: Flame retardant reinforced plastic

Environmental

Operating temperature: -25℃ ~ +70℃ Storage temperature: -40℃ ~ +85℃ Ambient humidity: 5~95% non‑condensing

Certification: CE Status: Original Siemens electrical spare

Installation

Cut off upstream power supply before replacement.

Fix breaker on the mounting base, connect incoming and outgoing power cables, confirm trip setting value, test closing, opening and tripping function after commissioning.

Interface

Three-phase main circuit terminals, optional auxiliary contact terminals, shunt release terminals.

Diagnostic

Overload trip: Load current exceeds setting value, poor heat dissipation. Instantaneous trip: Short-circuit fault on load side. Cannot close: Mechanical latch jam or internal interlock triggered.

Product Brief

3VL8716-2AA30-0AA0 breaker, Siemens 3VL 3-pole thermal-magnetic moulded case circuit breaker spare for low voltage power distribution cabinet and motor feeder protection replacement.
