AMAT 0100‑01363 Producer SE Signal Conditioning PCB Assembly

Technical Specifications

Model：0100‑01363（PCB reference number:0130‑01363）

Brand：AMAT Applied Materials

Product Type：Producer SE signal conditioning PCB assembly

Applicable System：AMAT Centura,Producer SE,P5000 Phase IV 200mm semiconductor process equipment,VME 6U chassis

Supply Voltage：5V,±12V VME backplane power supply

Bus Interface：VMEbus backplane interface

Logic Unit：FPGA embedded control logic

Common Revision：Rev 001

Status Indicator：Multi‑color LED for power,signal status and channel fault alarm

Built‑in Function：Chamber multi‑sensor signal conditioning,signal filtering and conversion,interlock signal processing,hardware self‑diagnosis,real‑time data transmission to main CPU via VME bus

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：VME slot plug‑in installation

Weight：0.78kg

Product Brief:

0100‑01363 is legacy Producer SE signal‑conditioning PCB assembly manufactured by AMAT Applied Materials. It is dedicated to processing analog and discrete sensor signals inside process chambers for Centura,Producer SE and P5000 semiconductor wafer equipment. It performs signal filtering,amplification and conversion,handles critical interlock signals,and transmits processed data to system main controller over VME backplane bus. Front‑panel LED indicators support quick on‑site channel and fault diagnosis without extra testing tools. Plug‑in VME slot structure enables convenient disassembly and replacement. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and equipment compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
