AMAT 0100‑09304 5000 System Wiring Distribution PCB Assembly

Technical Specifications

Model：0100‑09304

Brand：AMAT Applied Materials

Product Type：System wiring distribution PCB assembly

Applicable System：AMAT Precision 5000 200mm semiconductor process equipment

Supply Voltage：5V,±12V,24VDC multi‑rail power input

Interface：Multi‑pin high‑density power and signal connectors for system internal interconnection

Common Revision：Multiple hardware revisions available

Status Indicator：No on‑board LED,working status fed back by connected functional boards

Built‑in Function：System‑wide signal routing,power distribution,signal branching and transition,hardware circuit filtering,mechanical mounting positioning for internal wiring harness

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Fixed installation inside equipment chassis

Weight：0.51kg

Product Brief:

0100‑09304 is legacy system wiring distribution PCB assembly manufactured by AMAT Applied Materials. It acts as central signal and power distribution transition board inside Precision 5000 wafer fabrication equipment. It routes and distributes control signals,sensor signals and system power for multiple internal subsystems. Reliable high‑density connectors ensure stable signal and power transmission for long‑term production. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and equipment compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
