AMAT ABX‑X284 HV Capacitor Bank PCB Assembly

Technical Specifications

Model：ABX‑X284，Cross‑Ref P/N:0190‑18136

Brand：AMAT Applied Materials

Product Type：HV capacitor bank PCB assembly

Applicable System：AMAT Centura 200mm semiconductor process equipment

Supply Voltage：High‑voltage DC input

Interface：High‑voltage power connectors,system signal interconnection terminals

Common Revision：Rev F,Rev G,multiple hardware revisions available

Status Indicator：No onboard LED

Built‑in Function：High‑voltage energy storage,high‑voltage ripple filtering,transient‑voltage suppression,power‑supply noise reduction,stable high‑voltage output for chamber subsystems

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Chassis internal fixed installation

Weight：1.47kg

Product Brief:

ABX‑X284 is legacy HV capacitor bank PCB assembly manufactured by AMAT Applied Materials, functionally cross‑referenced to part number 0190‑18136. It is a dedicated high‑voltage energy‑storage and filter board for Centura wafer fabrication equipment. It suppresses high‑voltage ripple and transient interference,reduces power‑supply noise,and delivers stable high‑voltage power for process chamber subsystems. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and equipment compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
