KUKA KRC4 Robot Cabinet Controller

Technical Specifications

Model：KRC4

Brand：KUKA

Product Type：Robot cabinet controller

Version Variant：KRC4 compact,KRC4 smallsize‑2,standard KRC4,KRC4 midsize,KRC4 extended

Operating System：KSS system based on multi‑core industrial PC,SSD solid‑state storage

Matching Teach Pendant：smartPAD / smartPAD‑2

Programming Language：KRL(KUKA Robot Language),supports RSI real‑time sensor interface

Max Controlled Axes：Up to 16 axes(depends on cabinet variant),6 robot axes plus multiple external axes

Main Power Input：3‑Phase 208‑575V AC,50/60Hz

Internal Power & Drive：KPP power supply module,CCU central control unit with integrated safety PLC,KSD servo drive modules

Safety Standard：Compliant with ISO 13849‑1 PL e,SIL3 safety level

Communication Interface：Gigabit Ethernet,USB3.0,PROFIBUS‑DP,PROFINET,EtherCAT,DeviceNet,DVI‑I interface

I/O System：Support digital and analog I/O expansion via fieldbus,real‑time signal interaction with external PLC

Cabinet Dimension：Multiple size options according to cabinet variant,standard KRC4:960mm792mm558mm

Weight：150kg(standard cabinet variant)

Cabinet Protection Class：IP54

Working Ambient Temperature：+5℃ ~ +45℃

Structure：Layered modular cabinet architecture,filter‑free cooling design,hot‑swap partial internal modules for convenient inspection and replacement

Product Brief:

KRC4 is the fourth‑generation robot controller developed by KUKA,covering compact,smallsize‑2,standard,midsize and extended cabinet variants to match different robot payload and axis expansion requirements. It adopts multi‑core industrial PC plus CCU central control unit architecture,runs KSS robot system software with SSD solid‑state storage for faster system startup and higher data reliability. Integrated safety PLC realizes SIL3‑level safety logic processing,greatly improving system operation safety performance. Cooperate with smartPAD / smartPAD‑2 teach pendant to complete robot manual jogging,KRL program editing,RSI real‑time sensor coupling,parameter configuration and comprehensive fault diagnosis. Rich industrial bus interfaces support seamless connection with peripheral automation equipment,widely used in welding,handling,palletizing,assembly,machine tending and other automated production stations. This is mainstream robot spare component,used for system maintenance and module replacement of existing KRC4 robot systems. Please confirm robot mechanical model,cabinet variant,KSS software version and hardware revision before purchasing.
